Product Features:
1. Customizable ATS conversion and various input and output switches;
2. Adopt internationally renowned brand circuit breaker design, and realize customized output circuits according to actual needs;
3. Adopting the terminal distribution bus system design, the system output loop capacity expansion, troubleshooting, and three-phase balance adjustment of the load can be carried out without changing the power supply without changing any cables;
4. Intelligent monitoring function:
1) Realize busbar monitoring, including:
Three-phase input voltage, current, frequency, total power, active power, power factor, harmonic percentage, load percentage, electricity, etc.
2) Implementing branch circuit monitoring includes:
Branch rated current, actual current, branch load percentage, branch switch status, branch power (real-time power)
3) Supports rich alarm functions, including main distribution overvoltage, undervoltage, phase loss, power outage, overcurrent, ultra-high threshold, ultra-low threshold, frequency abnormality; branch over-current, ultra-high threshold, ultra-low threshold, switch Off, on, and system alarm functions.
4) Provides multiple intelligent interface communication methods of RS232/485 or SNMP, which can be uploaded through MODBUS protocol and easily incorporated into the computer room power monitoring system. Product advantages:
According to user requirements, a variety of accessories, emergency power-off switches, auxiliary contacts of each switch (alarm, fault, opening and closing indication, etc.) can be provided, and the main switch operation mode can be selected (direct handle operation, rotary handle operation, motor mechanism operation).
· Can operate normally in harsh environments: wide temperature operating range, can operate at an ambient temperature of 80℃ for a long time, resists ultraviolet radiation, and the appearance is not easy to age. All plastic components in the cabinet are flame retardant materials, with a temperature resistance of 960℃ , fully compliant with IEC695.2.1, NFC20-455 standards.
· The cabinet adopts a fully enclosed structure: glass door or mesh door for protection, dustproof, and 120-degree inclination for waterproofing. ***The protection level can be IP55, complying with IEC529 BS5420 standard.
